Automatic Folding and Packaging Machine for Thin Clothing FC

Automatic Folding and Packaging Machine for Thin Clothing FC

Contact number: 13538418048

Mailbox:2906246281@qq.com
Address:Room 202, Building 1, No. 13, Yinkai West Road, Dongcheng Street, Dongguan City, Guangdong Province
Source:http://www.yihongauto.com/cp1/4.html
Release time:2021-06-30




One: Equipment function
 1. This series of equipment is composed of the basic model FC-M112A, which can perform one-time folding of left and right garments, one to two vertical folding, automatic plastic bag feeding, and automatic bag filling actions.
2. The functional parts that can be added are: automatic heat-cut sealing parts, automatic tearing and sealing parts, and automatic stacking parts. Each component can be combined and used according to usage requirements.
3. The design of each part of the equipment is designed according to the speed requirement of 600pcs/H, any combination, the overall operation can reach this speed.
4. The device input interface is a touch screen input interface, which can store up to 99 kinds of clothing folding, bagging, sealing, and stacking operating parameters for easy selection.
2. Equipment characteristics
1. The equipment structure design is scientific, simple and highly reliable. It is convenient and quick to adjust and maintain, and easy to learn.
2. The basic model of the equipment can be easily combined with any parts. In any combination, the equipment can be disassembled into a transport body within 2 meters in length, and industrial standard elevators can be transported up and down.
 3. Applicable clothing


           Thin clothes, such as T-shirts, Polo shirts, casual shirts, etc.
 Four, product parameters

model

Minimum clothing width (mm)

Maximum clothing width (mm)

Minimum length of clothing (mm)

Maximum garment length (mm)

  LHK-F212

300

900

400

1050

Minimum width after folding (mm)

Maximum width after folding (mm)

Minimum length after folding (mm)

Maximum length after folding (mm)

170

380

200

400

Minimum size of plastic bag (mm)

Maximum size of plastic bag (mm)

The actual package of the machine (pcs/h)

Automatic sealing type

Length 280*width 200

Length 450 * Width 420

600

Optional

Voltage (V)

Air pressure (Mba)

Maximum power (KW)

Machine size (mm)

220

0.5~0.7

1.5

3000*960*1500


Five, work flow
  Place the clothes manually→automatically fold the edges on both sides→automatically convey to the half-folding station→automatically fold the first time→automatically forward the second half-fold→automatically convey to the bagging station
→Automatic bagging→One piece of clothing is packaged, and the next piece of clothing is cycled
       As shown below:
